Conical diamond scoring saw blade
Description:
Scoring saw blad for coated, veneered wood-based materials (such as chipboard, plywood and MDF). Finishing on the lower side of the panel.
Brazed polycrystalline diamond (PCD) tips. Flat sharpening. The minimum cutting thickness of the scoring saw blade must be the same as that of the main saw blade in order to match. Machining operations in feed. Can be re-sharpened 10-12 times.
Technical summary table:
| Cod. | D | SP | F | Z | FT | Macchina / Machine |
|---|---|---|---|---|---|---|
| 824.10031432020X | 100 | 3,1/4,3 | 20 | 20 | - | SCHELLING |
| 824.12031432024X | 120 | 3,1/4,3 | 20 | 24 | - | - |
| 824.12531432024X | 125 | 3,1/4,3 | 20 | 24 | - | PANHANS 693 EURO 5 |
| 824.12531432224X | 125 | 3,1/4,3 | 22 | 24 | - | MARTIN |
| 824.15043553036X | 150 | 4,3/5,5 | 30 | 36 | - | - |
| 824.16043555536X | 160 | 4,3/5,5 | 55 | 36 | - | GABBIANI |
| 824.18043553036X | 180 | 4,3/5,5 | 30 | 36 | 2(7/42) + 2(10/60) | PANHANS 693 |
| 824.18043554536X | 180 | 4,3/5,5 | 45 | 36 | HOLZMA | |
| 824.18047584536X | 180 | 4,7/5,8 | 45 | 36 | 3(13/80) | HOLZMA |
| 824.20043552036X | 200 | 4,3/5,5 | 20 | 36 | - | SCHELLING |
| 824.20043554536X | 200 | 4,3/5,5 | 45 | 36 | 3(7/66) | HOLZMA |
| 824.20043556536X | 200 | 4,3/5,5 | 65 | 36 | - | SELCO |
| 824.20043558036X | 200 | 4,3/5,5 | 80 | 36 | 2(9/60) | GABBIANI |
| 824.30043556572X | 300 | 4,3/5,5 | 65 | 72 | - | SELCO |
