Lama HW per canali
Descrizione:
Per scanalature.
Dente piano in HW.
Tabella tecnica riassuntiva:
| Cod. F30 | Cod. F35 | Cod. F40 | D | SP | Z |
|---|---|---|---|---|---|
| 190.140403036 | 190.140403536 | 190.140404036 | 140 | 4 | 36 |
| 190.140453036 | 190.140453536 | 190.140454036 | 140 | 4,5 | 36 |
| 190.140503036 | 190.140503536 | 190.140524036 | 140 | 5 | 36 |
| 190.140553036 | 190.140553536 | 190.140554036 | 140 | 5,5 | 36 |
| 190.140603036 | 190.140603536 | 190.140604036 | 140 | 6 | 36 |
| 190.140653036 | 190.140653536 | 190.140354036 | 140 | 6,5 | 36 |
| 190.150403036 | 190.150403536 | 190.150404036 | 150 | 4 | 36 |
| 190.150453036 | 190.150453536 | 190.150454036 | 150 | 4,5 | 36 |
| 190.150503036 | 190.150503536 | 190.150504036 | 150 | 5 | 36 |
| 190.150553036 | 190.150553536 | 190.150554036 | 150 | 5,5 | 36 |
| 190.150603036 | 190.150603536 | 190.150604036 | 150 | 6 | 36 |
| 190.150653036 | 190.150653536 | 190.150654036 | 150 | 6,5 | 36 |
| 190.160403036 | 190.160403536 | 190.160404036 | 160 | 4 | 36 |
| 190.160453036 | 190.160453536 | 190.160454036 | 160 | 4,5 | 36 |
| 190.160503036 | 190.160503536 | 190.160504036 | 160 | 5 | 36 |
| 190.160553036 | 190.160553536 | 190.160554036 | 160 | 5,5 | 36 |
| 190.160603036 | 190.160603536 | 190.160604036 | 160 | 6 | 36 |
| 190.160653036 | 190.160653536 | 190.160354036 | 160 | 6,5 | 36 |
| 190.180403040 | 190.180403540 | 190.180404040 | 180 | 4 | 40 |
| 190.180453040 | 190.180453540 | 190.180454040 | 180 | 4,5 | 40 |
| 190.180503040 | 190.180503540 | 190.180504040 | 180 | 5 | 40 |
| 190.180553040 | 190.180553540 | 190.180554040 | 180 | 5,5 | 40 |
| 190.180603040 | 190.180603540 | 190.180604040 | 180 | 6 | 40 |
| 190.180653040 | 190.180653540 | 190.180354040 | 180 | 6,5 | 40 |
| 190.200403032 | 190.200403532 | 190.200404032 | 200 | 4 | 32 |
| 190.200403040 | 190.200403540 | 190.200404040 | 200 | 4 | 40 |
| 190.200403048 | 190.200403548 | 190.200404048 | 200 | 4 | 48 |
| 190.200403064 | 190.200403564 | 190.200404064 | 200 | 4 | 64 |
| 190.200453032 | 190.200453532 | 190.200454032 | 200 | 4,5 | 32 |
| 190.200453040 | 190.200453540 | 190.200454040 | 200 | 4,5 | 40 |
| 190.200453048 | 190.200453548 | 190.200454048 | 200 | 4,5 | 48 |
| 190.200453064 | 190.200453564 | 190.200454064 | 200 | 4,5 | 64 |
| 190.200503032 | 190.200503532 | 190.200504032 | 200 | 5 | 32 |
| 190.200503040 | 190.200503540 | 190.200504040 | 200 | 5 | 40 |
| 190.200503048 | 190.200503548 | 190.200504048 | 200 | 5 | 48 |
| 190.200553032 | 190.200553532 | 190.200554032 | 200 | 5,5 | 32 |
| 190.200553048 | 190.200553548 | 190.200554048 | 200 | 5,5 | 48 |
| 190.200603032 | 190.200603532 | 190.200604032 | 200 | 6 | 32 |
| 190.200603048 | 190.200603548 | 190.200604048 | 200 | 6 | 48 |
| 190.200653032 | 190.200653532 | 190.200654032 | 200 | 6,5 | 32 |
| 190.200653048 | 190.200653548 | 190.200654048 | 200 | 6,5 | 48 |
| 190.250403040 | 190.250403540 | 190.250404040 | 250 | 4 | 40 |
| 190.250403060 | 190.250403560 | 190.250404060 | 250 | 4 | 60 |
| 190.250403080 | 190.250403580 | 190.250404080 | 250 | 4 | 80 |
| 190.250453040 | 190.250453540 | 190.250454040 | 250 | 4,5 | 40 |
| 190.250453060 | 190.250453560 | 190.250454060 | 250 | 4,5 | 60 |
| 190.250503040 | 190.250503540 | 190.250504040 | 250 | 5 | 40 |
| 190.250503060 | 190.250503560 | 190.250504060 | 250 | 5 | 60 |
| 190.250553040 | 190.250553540 | 190.250554040 | 250 | 5,5 | 40 |
| 190.250553060 | 190.250553560 | 190.250554060 | 250 | 5,5 | 60 |
| 190.250603040 | 190.250603540 | 190.250604040 | 250 | 6 | 40 |
| 190.250603060 | 190.250603560 | 190.250604060 | 250 | 6 | 60 |
| 190.250653040 | 190.250653540 | 190.250654040 | 250 | 6,5 | 40 |
| 190.250653060 | 190.250653560 | 190.250654060 | 250 | 6,5 | 60 |
| 190.300403048 | 190.300403548 | 190.300404048 | 300 | 4 | 48 |
| 190.300453048 | 190.300453548 | 190.300454048 | 300 | 4,5 | 48 |
| 190.300403072 | 190.300403572 | 190.300404072 | 300 | 4 | 72 |
| 190.300453072 | 190.300453572 | 190.300454072 | 300 | 4,5 | 72 |
| 190.300503048 | 190.300503548 | 190.300504048 | 300 | 5 | 48 |
| 190.300503072 | 190.300503572 | 190.300504072 | 300 | 5 | 72 |
| 190.300553048 | 190.300553548 | 190.300554048 | 300 | 5,5 | 48 |
| 190.300553072 | 190.300553572 | 190.300554072 | 300 | 5,5 | 72 |
| 190.300603048 | 190.300603548 | 190.300604048 | 300 | 6 | 48 |
| 190.300603072 | 190.300603572 | 190.300604072 | 300 | 6 | 72 |
| 190.300653048 | 190.300653548 | 190.300654048 | 300 | 6,5 | 48 |
| 190.300653072 | 190.300653572 | 190.300654072 | 300 | 6,5 | 72 |
