Lama HW per canali
Descrizione:
Per scanalature. Dente piano in HW.
Tabella tecnica riassuntiva:
| Cod. F30 | Cod. F35 | Cod. F40 | D | SP | Z |
|---|---|---|---|---|---|
| 190.120163012 | 190.120163512 | 190.120164012 | 120 | 1,6 | 12 |
| 190.120163024 | 190.120163524 | 190.120164024 | 120 | 1,6 | 24 |
| 190.120203012 | 190.120203512 | 190.120204012 | 120 | 2 | 12 |
| 190.120203024 | 190.120203524 | 190.120204024 | 120 | 2 | 24 |
| 190.120303012 | 190.120303512 | 190.120304012 | 120 | 3 | 12 |
| 190.120303024 | 190.120303524 | 190.120304024 | 120 | 3 | 24 |
| 190.120353012 | 190.120353512 | 190.120354012 | 120 | 3,5 | 12 |
| 190.120353024 | 190.120353524 | 190.120354024 | 120 | 3,5 | 24 |
| 190.120403012 | 190.120403512 | 190.123404012 | 120 | 4 | 12 |
| 190.120403024 | 190.120403524 | 190.120404024 | 120 | 4 | 24 |
| 190.120503012 | 190.120503512 | 190.120504012 | 120 | 5 | 12 |
| 190.120503024 | 190.120503524 | 190.120504024 | 120 | 5 | 24 |
| 190.120553012 | 190.120553512 | 190.120554012 | 120 | 5,5 | 12 |
| 190.120553024 | 190.120553524 | 190.120554024 | 120 | 5,5 | 24 |
| 190.120603012 | 190.120603512 | 190.120604012 | 120 | 6 | 12 |
| 190.120603024 | 190.120603524 | 190.120604024 | 120 | 6 | 24 |
| 190.120703012 | 190.120703512 | 190.120704012 | 120 | 7 | 12 |
| 190.120803012 | 190.120803512 | 190.120804012 | 120 | 8 | 12 |
| 190.120903012 | 190.120903012 | 190.120904012 | 120 | 9 | 12 |
| 190.1201003012 | 190.1201003512 | 190.1201004012 | 120 | 10 | 12 |
| 190.140163012 | 190.140163512 | 190.140164012 | 140 | 1,6 | 12 |
| 190.140163024 | 190.140163524 | 190.140164024 | 140 | 1,6 | 24 |
| 190.140203012 | 190.140203512 | 190.140204012 | 140 | 2 | 12 |
| 190.140203024 | 190.140203524 | 190.140204024 | 140 | 2 | 24 |
| 190.140303012 | 190.140303512 | 190.140304012 | 140 | 3 | 12 |
| 190.140303024 | 190.140303524 | 190.140304024 | 140 | 3 | 24 |
| 190.140353012 | 190.140353512 | 190.140354012 | 140 | 3,5 | 12 |
| 190.140353024 | 190.140353524 | 190.140354024 | 140 | 3,5 | 24 |
| 190.140403012 | 190.140403512 | 190.140404012 | 140 | 4 | 12 |
| 190.140403024 | 190.140403524 | 190.140404024 | 140 | 4 | 24 |
| 190.140503012 | 190.140503512 | 190.140504012 | 140 | 5 | 12 |
| 190.140503024 | 190.140503524 | 190.140504024 | 140 | 5 | 24 |
| 190.140553012 | 190.140553512 | 190.140554012 | 140 | 5,5 | 12 |
| 190.140553024 | 190.140553524 | 190.140554024 | 140 | 5,5 | 24 |
| 190.140603012 | 190.140603512 | 190.140604012 | 140 | 6 | 12 |
| 190.140603024 | 190.140603524 | 190.140604024 | 140 | 6 | 24 |
| 190.140703012 | 190.140703512 | 190.140704012 | 140 | 7 | 12 |
| 190.140703024 | 190.140703524 | 190.140704024 | 140 | 7 | 24 |
| 190.140803012 | 190.140803512 | 190.140804012 | 140 | 8 | 12 |
| 190.140803024 | 190.140803524 | 190.140804024 | 140 | 8 | 24 |
| 190.140903012 | 190.140903512 | 190.140904012 | 140 | 9 | 12 |
| 190.1601003024 | 190.1601003524 | 190.1601004024 | 160 | 10 | 24 |
| 190.180163024 | 190.180163524 | 190.180164024 | 180 | 1,6 | 24 |
| 190.180203024 | 190.180203524 | 190.180204024 | 180 | 2 | 24 |
| 190.180303024 | 190.180303524 | 190.180304024 | 180 | 3 | 24 |
| 190.180353024 | 190.180353524 | 190.180354024 | 180 | 3,5 | 24 |
| 190.180403024 | 190.180403524 | 190.180404024 | 180 | 4 | 24 |
| 190.180453024 | 190.180453524 | 190.180454024 | 180 | 4,5 | 24 |
| 190.180503024 | 190.180503524 | 190.180504024 | 180 | 5 | 24 |
| 190.180553024 | 190.180553524 | 190.180554024 | 180 | 5,5 | 24 |
| 190.180603024 | 190.180603524 | 190.180604024 | 180 | 6 | 24 |
| 190.180703024 | 190.180703524 | 190.180704024 | 180 | 7 | 24 |
| 190.180803024 | 190.180803524 | 190.180804024 | 180 | 8 | 24 |
| 190.180903024 | 190.180903524 | 190.180904024 | 180 | 9 | 24 |
| 190.1801003024 | 190.1801003524 | 190.1801004024 | 180 | 10 | 24 |
| 190.200163024 | 190.200163524 | 190.200164024 | 200 | 1,6 | 24 |
| 190.200203024 | 190.200203524 | 190.200204024 | 200 | 2 | 24 |
| 190.200303024 | 190.200303524 | 190.200304024 | 200 | 3 | 24 |
| 190.200353024 | 190.200353524 | 190.200354024 | 200 | 3,5 | 24 |
| 190.200403024 | 190.200403524 | 190.200404024 | 200 | 4 | 24 |
| 190.200453024 | 190.200453524 | 190.200453524 | 200 | 4,5 | 24 |
| 190.200503024 | 190.200503524 | 190.200504024 | 200 | 5 | 24 |
| 190.200553024 | 190.200553524 | 190.200554024 | 200 | 5,5 | 24 |
| 190.200603024 | 190.200603524 | 190.200304024 | 200 | 6 | 24 |
| 190.200703024 | 190.200703524 | 190.200704024 | 200 | 7 | 24 |
| 190.200803024 | 190.200803524 | 190.200804024 | 200 | 8 | 24 |
| 190.200903024 | 190.200903524 | 190.200904024 | 200 | 9 | 24 |
| 190.2001003024 | 190.2001003524 | 190.2001004024 | 200 | 10 | 24 |
